Arcum Tent
Arcum Tent is an ideal choice for many large-scale events and temporary venues due to its unique curved design, superior space utilization, stability and beautiful appearance. It not only provides a wide space for activities, but also has a high degree of safety, durability and flexibility, suitable for various climate conditions and different types of activities.
Materials: Aluminum alloy frame, PVC cloth (self-cleaning, fireproof)
Uses: Events, weddings, sports, military, product launches
Span Width：30m | 40m | 50m
| Model | Span (m) | Bay Distance (m) | Eave Height (m) | Top Height (m) | Roof Pitch | Spec Download |
| LTHX-10/400J | 10m | 5m | 4m | 5.50 | 20° | |
| LTHX-12/400J | 12m | 5m | 4m | 5.90 | 20° | |
| LTHX-15/400J | 15m | 5m | 4m | 6.50 | 20° | |
| LTHX-10/500K | 10m | 5m | 5m | 5.50 | 20° | |
| LTHX-12/500K | 12m | 5m | 5m | 5.90 | 20° | |
| LTHX-15/500K | 15m | 5m | 5m | 6.50 | 20° | |
| LTHX-20/500K | 20m | 5m | 5m | 7.50 | 20° | |
| LTHX-25/500K | 25m | 5m | 5m | 8.50 | 20° | |
| LTRX-20/500L | 20m | 5m | 5m | 8.2 | 20° | |
| LTRX-25/500L | 25m | 5m | 5m | 9.1 | 20° | |
| LTRX-30/500L | 30m | 5m | 5m | 9.9 | 20° | |
| LTRX-20/600L | 20m | 5m | 6m | 9.2 | 20° | |
| LTRX-25/600L | 25m | 5m | 6m | 10.1 | 20° | |
| LTRX-30/600L | 30m | 5m | 6m | 10.9 | 20° | |
| LTHX-30/600M | 30m | 5m | 6m | 10.60 | 20° | |
| LTHX-35/600M | 35m | 5m | 6m | 11.60 | 20° | |
| LTHX-40/600M | 40m | 5m | 6m | 12.60 | 20° | |
| LTHX-30-720M | 30m | 5m | 7.2m | 12.21 | 20° | |
| LTHX-35-720M | 35m | 5m | 7.2m | 13.06 | 20° | |
| LTHX-40-720M | 40 | 5 | 7.2 | 13.84 | 20° |
| Materials | Aluminum Alloy Frame |
| Q235 Steel Components / Stainless Steel Components | |
| Finish Treatment | Silver Positive Anodized Surface |
| Powder Coated and Painting | |
| Hot dip Galvanization for steel parts | |
| Color Options | Silver / Black/ White |
| Installation Way | Expansion bolts / Ground Stakes / Weight Plates |
| Max Wind Load | Up to 120km/h |
| Max Snow Load | Up to 0.5kn/sqm |
| Materials | High-Strength PVC Coated Fabric |
| Thickness Options | 650GSM / 750GSM / 850GSM / 950GSM / 1000GSM (transparent) |
| Color Options | White / Black / Grey / Customized option (to meet MOQ) |
| Light Transmittance | Opaque / Semi-Transparent / Full Transparent |
| Waterproof | Yes |
| UV Coated | Yes |
| Fire Retardent | Yes (DNI4102: B1, M2) |
| Sidewall | Soft PVC Fabric (thickness take cover materials for reference) |
| Sandwich Panel Wall | |
| ABS Panel Wall | |
| Tempered Glass Panel Wall | |
| Door | Fabric Door: Curtain-Open PVC Door, Zipper or String closure |
| Tempered Glass Door: Single-wing Glass door/ Double-wing Glass door | |
| Sliding Door: Glass Sliding Door, Sandwich Sliding Door | |
| Rolling Door: PVC Rolling Door / Alum. Rolling door / Steel Rolling Door | |
| Lining & Drapes | Lining and Drapes with various colors, with customzied waves against the request of structure. |
| Color: White as standard. | |
| Windows | Transparent PVC windows for PVC wall |
| Glass Awning Window / Glass Sliding Window for solid walls | |
| Flooring system | Simple wooden flooring system |
| Heavy Steel frame Modular fllooring system | |
| Heavy Alum. Modular Flooring System | |
| Secure Protection | Anti-collision Post with warning texture |
| Anti-collision Barriers with warning texture | |
| Others | Truss frames and stage system for events |
Get Your Custom Arcum Tent Quote Today!
Our experts are here to help discover the perfect solution for you.
Request a Free Quote
Our team is ready to get your projects now!
FAQs of LINGTONG Arcum Tent
What is an arcum tent?
An Arcum Tent is a curved-roof structure with modular aluminum frames (span 10-30m), using double PVC-coated fabric for waterproofing and flame resistance. Designed for events, exhibitions, and temporary storage, it supports wind speeds up to 100 km/h and offers customizable accessories like glass walls.
What are the structural features of Arcum Tent?
The Arcum Tent features a curved aluminum frame (15-40m span), modular design for flexible length adjustments, and flame-retardant double-layered PVC fabric (DIN4102 B1/M2). Its wind-resistant structure withstands 100 mph winds, with optional glass walls, rain gutters, and reinforced anchoring systems.
What is the difference between a tabernacle and a tent?
A tabernacle historically refers to a sacred, often portable sanctuary (e.g., biblical worship tents), while a tent is a secular, temporary shelter. Modern tents like the Arcum Tent use curved aluminum frames and flame-retardant PVC fabric for events, emphasizing modularity and wind resistance (up to 100 mph). Tabernacles hold religious significance, whereas tents prioritize practicality and adaptability.
Where is Arcum Tent commonly used?
The Arcum Tent is commonly used in large-scale exhibitions, events, and industrial storage due to its modular aluminum frame (15-40m span), wind resistance (up to 100 mph), and adaptable accessories like glass walls or rain gutters. It also serves military and emergency needs with quick assembly and durable PVC fabric.
What are military tents called?
Military tents are commonly called field shelters or combat tents, designed for tactical use. A notable example is the Arcum Tent, featuring modular aluminum frames and flame-retardant PVC fabric. They serve as command centers, barracks, or emergency shelters with wind resistance up to 100 mph.
