High Peak Tent
LINGTONG Tent’s High Peak Tent, crafted with aluminum alloy and PVC fabric, offers elegance and durability for Ramadan events, weddings, and exhibitions. Customizable and weather-resistant, it ensures unforgettable experiences.
Materials: Aluminum alloy frame, PVC fabric
Uses: Ramadan, weddings, exhibitions, parties
Span Width：3x3m to 10x10m, customizable
| Model | Span (m) | Bay Distance (m) | Eave Height(m) | Main Profile (mm) | Spec Download |
| TLJD-3/230C | 3m | 3m | 2.3m | φ63x2.5m（no groove） | |
| TLJD-3/230C | 4m | 4m | 2.3m | φ63x2.5m（no groove） | |
| TLJD-3/230C | 5m | 5m | 2.3m | φ63x2.5m（no groove） | |
| TLJD-3/230C | 6m | 6m | 2.3m | φ63x2.5m（no groove） | |
| TLJD-3X6/230C | 3m | 6m | 2.3m | φ63x2.5m（no groove） | |
| TLJD-4.5X9/230C | 4.5m | 9m | 2.3m | φ63x2.5m（no groove） | |
| TLJD-6X12/230C | 6m | 12m | 2.3m | φ63x2.5m（no groove） | |
| TLJD-3/230CI | 3m | 3m | 2.3m | φ63x2.5m（Double Inner grooves） | |
| TLJD-3/230CI | 4m | 4m | 2.3m | φ63x2.5m（Double Inner grooves） | |
| TLJD-3/230CI | 5m | 5m | 2.3m | φ63x2.5m（Double Inner grooves） | |
| TLJD-3/230CI | 6m | 6m | 2.3m | φ63x2.5m（Double Inner grooves） | |
| TLJD-3X6/230CI | 3m | 6m | 2.3m | φ63x2.5m（Double Inner grooves） | |
| TLJD-4.5X9/230CI | 4.5m | 9m | 2.3m | φ63x2.5m（Double Inner grooves） | |
| TLJD-6X12/230C | 6m | 12m | 2.3m | φ63x2.5m（Double Inner grooves） |
| Materials | Aluminum Alloy Frame |
| Q235 Steel Components / Stainless Steel Components | |
| Finish Treatment | Silver Positive Anodized Surface |
| Powder Coated and Painting | |
| Hot dip Galvanization for steel parts | |
| Color Options | Silver / Black/ White |
| Installation Way | Expansion bolts / Ground Stakes / Weight Plates |
| Materials | High-Strength PVC Coated Fabric |
| Thickness Options | 650GSM / 750GSM / 850GSM / 950GSM / 1000GSM (transparent) |
| Color Options | White / Black / Grey / Customized option (to meet MOQ) |
| Light Transmittance | Opaque / Semi-Transparent / Full Transparent |
| Waterproof | Yes |
| UV Coated | Yes |
| Fire Retardent | Yes (DNI4102: B1, M2) |
| Sidewall | Soft PVC Fabric (thickness take cover materials for reference) |
| Sandwich Panel Wall | |
| ABS Panel Wall | |
| Tempered Glass Panel Wall | |
| Door | Fabric Door: Curtain-Open PVC Door, Zipper or String closure |
| Tempered Glass Door: Single-wing Glass door/ Double-wing Glass door | |
| Sliding Door: Glass Sliding Door, Sandwich Sliding Door | |
| Rolling Door: PVC Rolling Door / Alum. Rolling door / Steel Rolling Door | |
| Lining & Drapes | Lining and Drapes with various colors, with customzied waves against the request of structure. |
| Color: White as standard. | |
| Windows | Transparent PVC windows for PVC wall |
| Glass Awning Window / Glass Sliding Window for solid walls | |
| Flooring system | Simple wooden flooring system |
| Heavy Steel frame Modular fllooring system | |
| Heavy Alum. Modular Flooring System | |
| Secure Protection | Anti-collision Post with warning texture |
| Anti-collision Barriers with warning texture | |
| Others | Truss frames and stage system for events |
Get Your Custom High Peak Tent Quote Today!
Our experts are here to help discover the perfect solution for you.
Request a Free Quote
Our team is ready to get your projects now!
FAQs of LINGTONG High Peak Tent
What is the tent made of?
The tent features an aluminum alloy frame and PVC fabric for durability.
Is the tent waterproof?
Yes, the PVC fabric is weather-resistant and waterproof.
How long does it take to set up?
The tent can be set up within 30 minutes with 2 people.
Can it be used for indoor events?
Yes, it is versatile for both indoor and outdoor use.
Is the tent flame-retardant?
Yes, the PVC fabric is flame-retardant to ensure safety.
